| MOTOR |
| Tip PACCAR MX300 EURO V |
| Nr. de cilindri |
6 |
| Alezaj / cursA? |
130/162 mm |
| Volum (cilindree) |
12,900 cm3 |
| Putere (net) |
300 kW/ 1,500 min-1 |
| Cuplu (net) |
2,000 Nm/ 1,000-1,410 min-1 |
| Noxe evacuare reglate prin Reductie Catalitica Selectiva |
|
|
| AMBREIAJ |
| Tip TATRA MFZ 1×430, monodisc |
|
|
CUTIE VITEZE
Manuala, tip ZF 16S 2230 TO |
| nr. de trepte inainte |
16 |
| inapoi |
2 |
CUTIE AUXILIARA
Tip TATRA 2.30 TR 1,28 coboratoare, o viteza |
|
|
| PRIZA DE PUTERE |
| Tip NH/1b de la cutia de viteze (1000 Nm) |
|
|
| AXE FATA |
| Directoare, motrice, cu semiaxe, cu decuplare actionare si diferentiale. |
| Perne de aer si amortizoare telescopice si stabilizator torsiune. |
|
|
| AXE SPATE |
| Motrice, cu semiaxe oscilante, blocari diferential, blocare diferential interaxial |
| Perne de aer si foi de arc |
|
|
| DIRECTIE |
| DirecA?ie compacta, cu volan pe partea stanga |
|
|
| FRANE |
| Patru sisteme separate de franare: operational, de urgenta, parcare si frana de evacuare |
|
|
| ANVELOPE, JANTE |
|
fata |
spate |
| Anvelope |
385/65 R22.5 |
315/80 R22.5 |
| Jante |
22.5×11.75 |
8.5×20 |
|
|
|
|
|
|
Toate cotele inaltimilorimilor se refera la vehicul incarcat |
|
|
|
|
| DIMENSIUNI |
|
| Latime |
2,500 mm |
|
| Ecartament fata |
1,942 mm |
|
| spate |
1,774 mm |
|
| Garda la sol |
280 mm |
|
|
|
|
| GREUTATI |
|
| Greutate proprie |
13,050 kg |
|
| Incarcare axe fata |
2 x 4,600 kg |
|
| Incarcare axe spate |
2 x 1,925 kg |
|
| Sarcina |
30,950 kg |
|
| GBV |
44,000 kg |
|
| Sarcina max. permisa axe fata |
2 x 9,000 kg |
|
| Sarcina max. permisa axe spate |
2 x 13,000 kg |
|
|
|
|
| ECHIPAMENT ELECTRIC |
|
| Tensiune circuit |
24 V |
|
| Baterii |
2x12V 170Ah |
|
| Generator (alternator) |
24 V/80 A |
|
|
|
|
| PERFORMANTE |
|
| Capacitate de urcare cu 44,000 kg |
52.0 % |
|
| Viteza max. cu limitator |
85 km/h |
|
| Diametru (exterior) de intoarcere |
20.0 1.0 m |
|
|
|
|
| CABINA
Alba, avansata, scurta, basculabila, incalzitor dependent cu apa. Doua locuri |
| REZERVOARE |
| Combustibil-otel, 300 l + 45 litri ADBlue |
|
